Gasket Selection Guide
On the below, is a list of available gasket materials and their respective applications.
-
Gasket Material, Range & Application Guide
Certain gasket materials are limited to specific plate heat exchanger ranges and model types.
Please check availability before ordering.
| Gasket Material | Typical Range | Typical Applications |
| NRB | -15 Degrees Celcius to 110 Degrees Celcius | Cooling / LTHW / Oils |
| NBR HT | -10 Degrees Celcius to 135 Degrees Celcius | Cooling / LT Hot water / Oils |
| HYDROGENATED NBR | -10 Degrees Celcius to 160 Degrees Celcius | HT Hot Water / Oils |
| EPDM | -25 Degrees Celcius to 150 Degrees Celcius | HT Hot water |
| EPDM HT | -10 Degrees Celcius to 160 Degrees Celcius | HT Hot Water |
| BUTYL | -10 Degrees Celcius to 160 Degrees Celcius | HT Oils & Solvents |
| HYPALON | -10 Degrees Celcius to 70 Degrees Celcius | Specialised Chemicals |
| VITON (FKM) A/B/G | -5 Degrees Celcius to 130 Degrees Celcius | HT Oils & Chemicals |
| NEOPRENE | -10 Degrees Celcius to 80 Degrees Celcius | Specialised Chemicals |
